UCCEAN Barcode
UCCEAN is a barcode widely used by many different companies and businesses for the exchange of goods and products. The barcode uses a list of Application Identifiers (AI) for formatting its structure. For example, an AI of 00 requires 18 digit numbers to be encoded into the barcode. The different AIs can also be mixed and matched to specify the format of the barcode.
Generating this barcode using the Barcode Generator
The easiest way to create this barcode is to use the Barcode Generator included in the installation package. Simply goto the Start Menu and launch Aeromium Barcode Fonts > Barcode Generator. This software automates
and simplifies the creation of the barcodes for you. After the barcode is created, you can simply copy
and paste the barcode into your documents.
Generating this barcode using the Barcode Generator
Generating this barcode in Excel
UCCEAN Barcode Fonts
The following is the list of fonts with varying heights supported by Aeromium for UCCEAN. It uses the same fonts as the Code 128 barcode.
FontCode128H1.ttf
FontCode128H2.ttf
FontCode128H3.ttf (Default Font)
FontCode128H4.ttf
FontCode128H5.ttf
FontCode128H6.ttf
Using this Barcode Manually
The UCCEAN barcode is based on Code 128 and thus follows the same rules as the Code 128 barcode. However the usage of the Application Identifiers involved certain amount of complexibties and thus the recommended way to create this barcode is to use the Barcode Generator or the Excel Add In.
| Application Identifiers | Data Type | Data Format |
| 00 | Serial Shipping Container Code (SSCC-18) | 18 numeric digits. |
| 01 | Global Tade Item Number | 14 numeric digits. |
| 02 | Goods contained in another Unit | 14 numeric digits. |
| 10 | Batch or Lot Number | Up to 20 Alphanumeric characters. |
| 11 | Production Date | YYMMDD |
| 12 | Due Date | YYMMDD |
| 13 | Packaging Date | YYMMDD |
| 15 | Sell By Date | YYMMDD |
| 17 | Expiration Date | YYMMDD |
| 20 | Product Variant | 2 numeric digits. |
| 21 | Serial Number | Up to 20 Alphanumeric characters. |
| 22 | Health Industry Data | Up to 29 Alphanumeric characters. |
| 23n | Lot Number | 1 numeric digit for the Length Indicator. And up to 19 numeric digits for the data. |
| 240 | Additional Product ID assigned by Manufacturer | Up to 30 Alphanumeric characters. |
| 241 | Customer Part Number | Up to 30 Alphanumeric characters. |
| 250 | Secondary Serial Number | Up to 30 Alphanumeric characters. |
| 251 | Reference to Source Entity | Up to 30 Alphanumeric characters. |
| 30 | Quantity | Up to 8 numeric digits |
| 310n | Net Weight - Kilograms | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 311n | Length/First Dimension - Meters | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 312n | Width/Diameter/2nd Dimension - Meters | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 313n | Depth/Thickness/Height/3rd Dimension - Meters | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 314n | Area - Square Meters | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 315n | Volume - Litres | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 316n | Volume - Cubic Meters | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 320n | Net Weight - Pounds | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 321n | Length/First Dimension - Inches | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 322n | Length/First Dimension - Feet | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 323n | Length/First Dimension - Yards | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 324n | Width/Diameter/Second Dimension - Inches | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 325n | Width/Diameter/Second Dimension - Feet | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 326n | Width/Diameter/Second Dimension - Yards | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 327n | Depth/Thickness/Third Dimension - Inches | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 328n | Depth/Thickness/Third Dimension - Feet | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 329n | Depth/Thickness/Third Dimension - Yards | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 330n | Gross Weight - Kilograms | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 331n | Length/First Dimension - Meters | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 332n | Width/Diameter/Second Dimension - Meters | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 333n | Depth/Thickness/Height/Third Dimension - Meters | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 334n | Area - Square Meters | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 335n | Volume - Litres | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 336n | Volume - Cubic Meters | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 337n | Kilograms per Square Meters | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 340n | Weight - Pounds | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 341n | Length/First Dimension - Inches | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 342n | Length/First Dimension - Feet | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 343n | Length/First Dimension - Yards | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 344n | Width/Diameter/Second Dimension - Inches | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 345n | Width/Diameter/Second Dimension - Feet | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 346n | Width/Diameter/Second Dimension - Yards | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 347n | Depth/Thickness/Height/Third Dimension - Inches | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 348n | Depth/Thickness/Height/Third Dimension - Feet | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 349n | Depth/Thickness/Height/Third Dimension - Yards | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 350n | Area - Square Inches | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 351n | Area - Square Feet | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 352n | Area - Square Yards | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 353n | Container Area - Square Inches | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 354n | Container Area - Square Feet | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 355n | Container Area - Square Yards | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 356n | Net Weight - Troy ounces | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 357n | Net Volume - Ounces | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 360n | Net Volume - Quarts | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 361n | Net Volume - Gallons | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 362n | Gross Volume - Quarts | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 363n | Gross Volume - Gallons | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 364n | Volume - Cubic Inches | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 365n | Volume - Cubic Feet | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 366n | Volume - Cubic Yards | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 367n | Gross Volume - Cubic Inches | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 368n | Gross Volume - Cubic Feet | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 369n | Gross Volume - Cubic Yards | 1 numeric digit for Decimal Point Position. And 6 numeric digits for data. |
| 37 | Number of Items Contained | Up to 8 numeric digits. |
| 400 | Customer's Purchase Order Number | Up to 30 Alphanumeric characters |
| 401 | Consignment Number | Up to 30 Alphanumeric characters. |
| 402 | Shipment Identification Number | 17 numeric digits. |
| 403 | Routing Code | Up to 30 Alphanumeric characters. |
| 410 | Ship to/Deliver to Location | 13 numeric digits. |
| 411 | Bill to/Invoice to Location | 13 numeric digits. |
| 412 | Purchased From Location | 13 numeric digits. |
| 413 | Ship to/Deliver For Location | 13 numeric digits. |
| 414 | Identification of a Physical Location | 13 numeric digits. |
| 415 | Global Location Number | 13 numeric digits. |
| 420 | Ship to/Deliver to Postal Code within a Single Postal Authority | Up to 9 Alphanumeric characters. |
| 421 | Ship to/Deliver to Postal Code With Three-Digit ISO Country Code | 3 numeric digits Country Code. And up to 9 Alphanumeric characters. |
| 422 | Country of Origin of a Trade Item | 3 numeric digits. |
| 423 | Country of Initial Processing | 3 numeric digits |
| 424 | Country of Processing | 3 numeric digits |
| 425 | Country of Disassembly | 3 numeric digits. |
| 426 | Country Covering Full Process Chain | 3 numeric digits. |
| 8001 | Roll products - Width, Length, Core Diameter, Direction and Splices | 14 numeric digits. |
| 8002 | Electronic Serial ID for Cellular Mobile Telephones | Up to 20 Alphanumeric characters. |
| 8003 | EAN/UCC Returnable Asset Identifier | 14 numeric digits. And up to 16 Alphanumeric characters. |
| 8004 | Global Individual Asset Identifier | Up to 30 Alphanumeric characters. |
| 8005 | Price per unit of measure | 6 numeric digits |
| 8100 | Coupon Extended Code | 6 numeric digits. |
| 8101 | Coupon Extended Code | 10 numeric digits. |
| 8102 | Coupon Extended Code | 2 numeric digits. |
| 90 | Information mutually agreed between Trading Partners | Up to 30 Alphanumeric characters. |
| 91 | Company internal use | Up to 30 Alphanumeric characters. |
| 92 | Company internal use | Up to 30 Alphanumeric characters. |
| 93 | Company internal use | Up to 30 Alphanumeric characters. |
| 94 | Company internal use | Up to 30 Alphanumeric characters. |
| 95 | Company internal use | Up to 30 Alphanumeric characters. |
| 96 | Company internal use | Up to 30 Alphanumeric characters. |
| 97 | Company internal use | Up to 30 Alphanumeric characters. |
| 98 | Company internal use | Up to 30 Alphanumeric characters. |
| 99 | Company internal use | Up to 30 Alphanumeric characters. |
Examples
To encode the Serial Shipping Container Code (SSCC-18), use the AI "(00)" followed by 18 numeric digits. For example "(00)987987345234852341" and select the FontCode39H3.ttf font. The output is as follows :
Additional AI can be added to the end of the data as follows : "(00)987987345234852341(10)100Z"
